• Novo
zoom_out_map

Motherboard ASUS TUF GAMING Z890-PLUS WIFI

Campanha - Cashback de 25€. Válida até 04/12/2024. Mais info

Part number:  90MB1IQ0-M0EAY0   EAN:  4711387763926

Estado: Novo    Disponibilidade: schedule Brevemente/Encomenda

PVP: 347,94 €
Com IVA
Quantidade

Adicionar a wishlist

- Os preços dos produtos podem ser alterados sem aviso prévio.

- As imagens podem não corresponder na integra ao produto.

A TUF Gaming Z890-Plus WiFi oferece desempenho confiável e durabilidade, ideal para gamers e criadores de conteúdo.
Com suporte para os mais recentes processadores Intel, DDR5 e PCIe 5.0, garante uma performance sólida. Equipada com Wi-Fi 7,
refrigeração otimizada e componentes de nível militar, esta motherboard é construída para durar, oferecendo uma experiência de jogo estável e robusta com o estilo distinto da linha TUF.

Desempenho
Suporte para processadores Intel® Core™ Ultra (Série 2) LGA1851 e memória DDR5 com overclock até 8600+MT/s.
Recursos avançados como AI Overclocking, DIMM Fit e AEMP III para otimização de desempenho.

Arrefecimento
AI Cooling II reduz o ruído das ventoinhas e ajusta dinamicamente a curva de ventoinha.
Vários cabeçalhos de ventoinha e bomba, além de dissipadores térmicos robustos para VRM e slots M.2.

Conectividade
Wi-Fi 7 com largura de banda de 160MHz e Bluetooth® v5.4.
Várias portas USB, incluindo Thunderbolt™ 4, USB Type-C® e suporte para RAID.

Áudio
Codec de áudio Realtek ALC1220P 7.1 Surround Sound com suporte a até 32-Bit/192 kHz.
Recursos de áudio premium como detecção de jack, capacitores de alta qualidade e saída óptica S/PDIF.

Design
Design TUF Gaming com recursos de fácil instalação como M.2 Q-Latch e Q-Release.
Iluminação RGB com suporte para Aura Sync e cabeçalhos Gen 2 endereçáveis.

CPU Support Intel® Core™ Ultra Processors(series 2), LGA1851*
Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
* Refer to https://www.asus.com/support/download-center/ for CPU support list.
** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.
Chipset  Intel® Z890 Chipset
Memory  4 x DIMM slots, max. 192GB, DDR5
Support up to 8600+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)*
Dual channel memory architecture
DIMM Fit
Supports Intel® Extreme Memory Profile (XMP) memory module
ASUS Enhanced Memory Profile III(AEMPIII)

* Supported memory types, data rate (speed), and number of DRAM modules vary

depending on the CPU and memory configuration, for more information please refer to CPU/Memory

Support list under the Support tab of product information site or visit

https://www.asus.com/support/download-center/.
** Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
Graphics 1 x DisplayPort**
1 x HDMI™ port***
1 x Intel® Thunderbolt™ 4 port (USB Type-C®) supports DisplayPort and Thunderbolt™ video outputs****
1 x USB 20Gbps port supports USB Type-C® display output*****
* Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
** Supports max. 4K@60Hz as specified in DisplayPort 1.4.
*** Supports 4K@60Hz as specified in HDMI 2.1.

****Supports up to 8K@60Hz x1 with DSC, maximum total bandwidth up to 23.8Gbps,

for resolution support please check DisplayPort 2.1 specs.
***** Supports max. 4K@60Hz as specified in DisplayPort 1.4.
****** VGA resolution support depends on processors' or graphic cards' resolution.
Expansion Slots  Intel® Core™ Ultra Processors(series 2)*
1 x PCIe 5.0 x16 slot
Intel® Z890 Chipset
1 x PCIe 4.0 x16 slot (supports x4 mode)
1 x PCIe 4.0 x4 slot
2 x PCIe 4.0 x1 slots

* Please check the PCIe bifurcation table on the support

site (https://www.asus.com/support/FAQ/1037507/).

- To ensure compatibility of the device installed, please refer

to https://www.asus.com/support/download-center/ for the list of supported peripherals.
Storage  Total Supports 4 x M.2 slots and 4 x SATA 6Gb/s ports*
Intel® Core™ Ultra Processors(series 2) *
M.2_1 slot (Key M), type 2242/2260/2280  (supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
Intel® Z890 Chipset
M.2_3 slot (Key M), type 2280/22110 (supports PCIe 4.0 x4 mode)
M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes)
4 x SATA 6Gb/s ports

* Intel® Rapid Storage Technology supports PCIe RAID 0/1/5/10,

SATA RAID 0/1/5/10, M.2 slot from CPU only support RAID 0/1/5.
Ethernet 1 x Intel® 2.5Gb Ethernet
TUF LANGuard
Wireless & Bluetooth®

Wi-Fi 7*
2x2 Wi-Fi 7 (802.11be)
Supports 2.4/5/6GHz frequency band**
Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate.
Bluetooth® v5.4***

*Wi-Fi features may vary depending on the operating system
 For Windows 11, Wi-Fi 7 will require  24H2 or later version for full functions,

Windows 11 21H2/22H2/23H2 only support Wi-Fi 6E.
 For Windows 10, please note that no driver is available , please refer to the

Wi-Fi chipset vendor's website for details.
** Wi-Fi 6GHz frequency band and bandwidth regulatory may vary between countries.
*** The Bluetooth® version may vary, please refer to the Wi-Fi module

manufacturer's website for the latest specifications.
USB  Rear USB (Total 8 ports)
1 x Thunderbolt™ 4 port (1 x USB Type-C®)
1 x USB 20Gbps port (1 x USB Type-C®)
3 x USB 10Gbps ports (3 x Type-A)
3 x USB 5Gbps ports (3 x Type-A)
Front USB (Total 7 ports)
1 x USB 20Gbps connector (supports USB Type-C®)
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
Audio Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC*
- Impedance sense for front and rear headphone outputs
- Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
- Supports up to 32-Bit/192 kHz playback*
Audio Features
- Audio Shielding
- Rear optical S/PDIF out port
- Premium audio capacitors
- Dedicated audio PCB layers
- Audio cover
- Unique de-pop circuit
* Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio.
Back Panel I/O Ports  1 x Thunderbolt™ 4 USB Type-C® port
1 x USB 20Gbps port (1 x USB Type-C® with DP Alt mode)
3 x USB 10Gbps ports (3 x Type-A)
3 x USB 5Gbps ports (3 x Type-A)
1 x DisplayPort
1 x HDMI™ port
1 x Wi-Fi module
1 x Intel® 2.5Gb Ethernet port
5 x Audio jacks
1 x Optical S/PDIF out port
1 x BIOS FlashBack™ button
Internal I/O Connectors Fan and Cooling Related
1 x 4-pin CPU Fan header
1 x 4-pin CPU OPT Fan header
1 x 4-pin AIO Pump header
4 x 4-pin Chassis Fan headers
Power Related
1 x 24-pin Main Power connector
2 x 8-pin +12V CPU Power connector
Storage Related
4 x M.2 slots (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 20Gbps connector (supports USB Type-C® )
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
2 x USB 2.0 headers support 4 additional USB 2.0 ports
Miscellaneous
3 x Addressable Gen 2 headers
1 x Clear CMOS header
1 x Chassis Intrusion header
1 x COM Port header
1 x Front Panel Audio header (F_AUDIO)
1 x 10-1 pin Front System Panel header
1 x Thunderbolt™ (USB4®) header
Special Features  ASUS TUF PROTECTION
- DIGI+ VRM (- Digital power design with DrMOS)
- ESD Guards
- TUF LANGuard
- Overvoltage protection
- SafeSlot
- Stainless-steel back I/O
ASUS Q-Design
- M.2 Q-Latch
- M.2 Q-Release
- M.2 Q-Slide
- PCIe Slot Q-Release
- Q-Antenna
- Q-Dashboard
- Q-DIMM
- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
- Q-Slot
ASUS Thermal Solution
- M.2 heatsink backplate
- M.2 heatsink
- VRM heatsink design
ASUS EZ DIY
- BIOS FlashBack™ button
- BIOS FlashBack™ LED
- CPU Socket lever protector
- ProCool
- Pre-mounted I/O shield
- SafeDIMM
Aura Sync
- Addressable Gen 2 headers
Software Features ASUS Exclusive Software
Armoury Crate
- Aura Creator
- Aura Sync
- Fan Xpert 4 (with AI Cooling II)
- Power Saving
ASUS DriverHub
ASUS GlideX
TurboV Core
TUF GAMING CPU-Z
DTS Audio Processing
Norton 360 for Gamers (60 Days Free Trial)
WinRAR (40 Days Free Trial)
UEFI BIOS
AI Overclocking Guide
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
- ASUS MyHotkey
FlexKey
NPU Boost
BIOS  256 Mb Flash ROM, UEFI AMI BIOS
Manageability  WOL by PME, PXE
Accessories  Cables
2 x SATA 6Gb/s cables
Miscellaneous
1 x ASUS WiFi Q-Antenna
1 x M.2 Q-Slide package
2 x M.2 rubber packages
1 x Screw package for M.2 SSD
1 x TUF GAMING sticker
Documentation
1 x Quick start guide
Operating System  Windows 11  (22H2 & later)
Form Factor  ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )

Ficha de dados

Fabricante do processador
Intel
Motherboard chipset
Intel Z890
Quantidade de slots de memória
4
Tipos de memórias compatíveis
DDR5-SDRAM
Socket do processador
LGA 1851 (Socket V1)
Forma da motherboard
ATX

Referências Específicas

Novo
